- Description
Brief description
Power supply: 3P AC208-415V 50/60Hz, lifting angle: conventional 45 degrees, customizable for any angle within 30-60 degrees; Height increase: Regular 1.85 meters, customizable 1-5 meters;
Main features
Power supply: 3P AC208-415V 50/60Hz
Elevation angle: Conventional 45 degrees, customizable to any angle within 30-60 degrees;
Height increase: Regular 1.85 meters, customizable 1-5 meters;
Delivery capacity: In addition to the delivery capacities listed above, other delivery capacities can also be customized;
Bottom feeding can also be selected without a material box and directly connected to the front equipment;
The feeding tube is a 'U' - shaped groove with a stainless steel arc-shaped cover, which is fastened with a buckle and sealed with a sealing strip in the middle to prevent powder leakage. The cover can be opened for easy cleaning;
All stainless steel structure, with material contact parts made of 304 material.
Main parameters
model | DH-US2-2K | DH-US2-3K | DH-US2-5K | DH-US2-7K | DH-US2-8K | DH-US2-12K |
increase speed | 2m3/h | 3m3/h | 5 m3/h | 7 m3/h | 8 m3/h | 12 m3/h |
Feeding pipe diameter | Φ102 | Φ114 | Φ141 | Φ159 | Φ168 | Φ219 |
Total machine power | 0.58KW | 0.78W | 1.53KW | 1.53KW | 3.03KW | 4.03KW |
Total weight | 100kg | 130kg | 170kg | 200kg | 220kg | 270kg |
bin volume | 100L | 200L | 200L | 200L | 200L | 200L |
